Stainless Steel TP304 / TP304L Capillary Tubes Suppliers; Stainless Steel TP304 / TP304L Capillary Tubes Exporter.
Bombay Metal Corporation is one of the well – known trader and dealer of quality Stainless Steel TP304 / TP304L Capillary Tubes, where along with alloy chemistry, metal dusting resistance is influenced by grain size. Stainless Steel TP304 / TP304L Capillary Tubes has good resistance to corrosion and oxidation along with high tensile and creep – rupture properties at temperatures to 1300 Degree F. Stainless Steel TP304 / TP304L Capillary Tubes is used in gas turbines, rocket engines, nuclear reactors, pressure vessels, tooling, and aircraft structures.
Stainless Steel TP304 / TP304L Capillary Tubes possesses some extra-ordinary abilities that complement its use. These tubes are highly resistant to all forms of corrosion, such as pitting am crevice corrosion due to chlorides in the environment. These Tubes also are highly flexible and can be installed and removed easily. These tubes also have the capability to withstand high temperatures and pressure. They are made leakproof with a subtle finish and attractive appearance.
Specifications of Stainless Steel TP304 / TP304L Capillary Tubes :
Specifications : ASTM A213 / ASME SA213
Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Capillary/ Seamless / ERW / Fabricated / CDW
Form : Round Tubes, Square Tubes, Rectangular Tubes.
Length : Single Random, Double Random & Required Length
These Stainless Steel TP304 / TP304L Capillary Tubes offered by Bombay Metal Corporation is austenite steel, which stains less easily than other iron-based metals, but it’s not literally stainless. It is not very electrically or thermally conductive and is non – magnetic. These Stainless Steel TP304 / TP304L Capillary Tubes has a higher corrosion resistance than regular steel and is widely used because of the ease in which it is formed into various shapes. There are various grades and surface finishes of stainless steel to suit the environment the alloy must endure.
Contact – 8022222767
Email – bombaymetalcorp@gmail.com
Equivalent Grades Of Stainless Steel TP304 / TP304L Capillary Tubes:
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS TP304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
| SS TP304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Stainless Steel TP304 / TP304L Capillary Tubes Chemical Composition:
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS TP304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| SS TP304L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 13 | – |
Stainless Steel TP304 / TP304L Capillary Tubes Mechanical Properties:
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS TP304 / TP304L | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
